Rüsch 800/1500G image

Rüsch 800/1500G

800/1500G, semi-automatic bandsawing machine for graded cuts, with two load-bearing columns with sliding on recirculating ball linear guides, electric table rotation with pneumatic locking at the desired degree. Ideal sawing machine for automatic cutting line configurations with loading and unloading. High performance combined with cutting precision even in the most demanding jobs. Sawing machine that is at the top of its segment.

Description

Electric swivel base rotation.
Pneumatic swivel base locking.
Digital display of the cutting angle.
Machine stop system in case of blade breakage.
Pressure reducing valve for the workpiece closing vice ( allows you to cut thin tubes without deforming them ).
Arc return cycle over the piece once the cut has been made.
Oil pump shutdown timer if the machine is not used.

Cutting capacity		Technical parameters
Round - Angle 90°	800 mm	Sawing speed	20 – 120 m/min
Square - Angle 90°	800 mm	Main motor	7.5 kW
Rectangle - Angle 90°	1500 х800 mm	Cooling Oil motor	1.5 kW
Round - Angle 45°	800 mm	Cooling motor H2O	1.1 kW
Square - Angle 45°	800 mm	Blade size	11100 х 54 х 1.6 mm
Rectangle - Angle 45°	940 х 800 mm	Working height	950 mm
Round - Angle 60°	580 mm	Dimensions, min	6300 x 4200 x 3200 mm
Square - Angle 60°	580 mm	Weight	14500 Kg
Rectangle - Angle 60°	580 х 800 mm	Color	RAL 7035 RAL 7037
Round - Angle - 45°	800 mm
Square - Angle - 45°	800 mm
Rectangle - Angle - 45°	940 х 600 mm
Round - Angle - 60°	470 mm
Square - Angle - 60°	470 mm
Rectangle - Angle - 60°	470 х 800 mm
