Basic Description:
Works with straight, round, and oval pipes
Maximum diameter Ø150 mm (for straight pipes)
Excellent machining results: thanks to the planetary machining system
The feed system is easily removed for bent pipes
Includes:
1. Automatic feed with 2 double feed rollers
2. Inverter for automatic feed, controlled by a digital display
3. Inverter for processing belts, controlled by a digital display
4. Emergency magnetic switch
5. Pedal for unlocking and opening belts
6. CE safety system
Technical specifications:
Working size (Ø mm) | 30 - 150 |
Automatic feed speed (m/m) number 1 and 2 | 1 - 4 |
Belt speed (m/sec) number 3 | 10 - 30 |
Belt motor (kW) | 5,5 |
Wheel motor (kW) | 2,2 |
Feed motor power (kW) | 2 x 0,18 |
Belt size (mm) | 1100 x 50 |
Consumption (A) | 16 |
Dimensions (mm) | 1150 X 1000 X 1300 |
Weight (kg) | 550 |
