Laser cutting of pipes and profiles

Laser cutting of tubes is a modern metalworking technology offering a number of significant advantages over traditional cutting methods. The cutting element of the machine is a high-power laser beam, which instantly vaporizes the metal at the focal point without causing any mechanical stress to the workpiece. This method allows for the processing of thin, easily deformed tubes without the risk of them losing their shape.

The advantages and benefits of laser metal processing include:

the absence of any defects on the cut surface, such as chips or burrs, allows for high-quality joining of parts;
the processing of tubes and profiles of any cross-section (round, rectangular, or square);
laser cutting does not deform the material, nor does it cause the accumulation of internal stress or structural defects in the metal, which directly impacts the durability of the finished products;
the laser cut line can be not only straight but also have a complex, curved shape, which is unachievable with mechanical tools;
the high quality and precision of the cutting process eliminates the need for additional trimming, saving time and costs.

We offer:

D mm of tube Min - Max	Profile, mm Min - Max	KW	Type of Cutting head	Loading length, m	Unloading Length, m
10 – 42*3	1515 - 4040	1 - 3	2D	3 - 6	10 - 1800
15 - 120*4	1515 – 100100*4	1.5 - 2	2D	3 - 6	0 - 6
15 - 160	2020 – 110110	1.5 - 6	2D / 3D	6	0 – 6
20 - 220	2020 – 150150	1 - 12	2D	6.5 -9.2	0 - 6
20 – 220	2020 – 220220	1 - 6	2D	6.2	0 - 6
20 - 220	2020 – 220220	1 - 20	2D / 3D	6.0 – 6.2	0 – 3 - 6
20 – 320	2020 – 220220	1 - 20	2D / 3D	6 - 12	3 – 6 – 9 - 12
20 - 360	2020 – 220220	1 - 15	2D	6.5 -9.2	0 - 6
20 - 360	2020 – 220220	1 - 30	2D / 3D	6 - 9 - 12	3 – 6 – 9 - 12
20 - 360	2525 – 350350	1 - 30	2D / 3D	6 - 9 - 12	3 – 6 – 9 - 12
20 - 450	2525 – 400400	6 - 60	2D / 3D	6 -9 - 12	3 – 6 – 9 - 12
25 - 515	2525 – 515515	6 – 60	2D / 3D	6 – 9 - 12	3 – 6 – 9 - 12
100 - 1000	100mm≤Width≤1000mm	12 - 60	2D / 3D	6 - 9 - 12	3 – 6 – 9 – 12

Advantages of a laser cutting machine for pipes and profiles:

• High cutting speed

• High cutting accuracy

• Non-contact processing

• Energy-efficient and environmentally friendly

• Adaptability to various materials

We offer a wide selection of laser pipe and profile cutters, from budget-friendly solutions to machines capable of cutting pipes and profiles up to 1000 mm in diameter, with 2D or 3D heads (Boci, Raytools Precitec…), and various sources (Max, IPG, BWT, Raycus…) and control systems.

Manufacturer: LXSHOW (China)

Manufacturer: Eeto (China)

Manufacturer: Uni-Kat (Poland)

Manufacturer: OMP (Italy)

Manufacturer: Warcom (Italy)

An automatic loading system and other automated equipment are available to our customers.

We will find the best laser machine solution for you with a 100% service guarantee.
